  • 09330162601

09330162601

Názov produktu: Han E 16 Pos. M Insert Screw

Výrobca: HARTING

Dostupnosť: Skladom 105ks
Katalógová cena: 11.25€
Vaša cena:

10.35€ / ks

13.50€ s DPH: 12.42€

Inserts
Screw termination
Male
Polycarbonate (PC)
RAL 7032 (pebble grey)
Rated current: ‌16 A
Size: 16 B
Contacts: 16
Conductor cross-section: 0.75 ... 2.5 mm²
Copper alloy
Silver plated
Rated surge voltage 6 kV
Rated current In 16 A
Contact design Pin
max. connectable conductor cross-section multiple wire 2.5 mm²
min. connectable conductor cross-section multiple wire 0.75 mm²
wire protection present Yes
PE connection present Yes
Material of the contact coat Silver
Material of the contact Other copper alloys
Min. operating temperature -40 °C
Max. operating temperature 125 °C
material connector of connector insert Thermoplast
Product type Han E 16 Pos. M Insert Screw
product article number of manufacturer 09 33 016 2601
Manufacturer name HARTING Technology Group
Brand Han E®
Application standards EN 60664-1
Conductor connection method Screw connection
Size 16 B
Insertion cycles, min. 500
Number of power contacts 16
Pole number 16
Manufacturer product description Inserts, Screw termination, Male, Polycarbonate (PC), RAL 7032 (pebble grey), Rated current
Degree of soiling 3
Combustibility class V0
Max. line cross section, flexible 2.5 mm²
Min. line cross section, flexible 0.75 mm²
rated voltage 500 V
